- General Information
- Manufacturer
- ViewSonic Corporation
- Manufacturer Website Address
- http://www.viewsonic.com
- Brand Name
- ViewSonic
- Product Series
- LDP
- Product Type
- Digital Signage Display
The ViewSonic® LDP Performance Series are pre-configured all-in-one commercial Direct View LED displays that brings big-screen visuals at a 4K resolution to high-end venues like lobbies, boardrooms, auditoriums, and more. The LDP Performance series builds on the simplicity and accessibility of the LDM Series with the addition of Chip On Board (COB) technology to achieve a stunning 4K UHD resolution in 136" , 163" , and 217" sizes. Specifcation, purchasing, and installation is made easy with a single part number that includes everything needed for a standard installation. Optional accessory kits are available for separate and hidden control bar installations. With 600-nit brightness, a 10,000:1 contrast ratio, and dual 30W speakers, this large format LED display delivers vivid visuals and immersive sound for an exceptional viewing experience.
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
3-year limited warranty on parts and labor on-site service
- Technical Information
- HDCP Version
- 2.2
- Ingress Protection (IP) Rating
- IP54
- Impact Protection (IK) Rating
- IK08
- Processor & Chipset
- Processor Manufacturer
- Rockchip
- Processor Model
- RK3399
- Memory
- Standard Memory
- 4 GB
- Memory Technology
- DDR4 SDRAM
- Display & Graphics
- Number of Screens
- 1
- Viewable Screen Size
- 18.08 ft
- Screen Size Class
- 18.08 ft
- Display Screen Type
- LCD
- Display Resolution
- 3840 x 2160
- Pixel Pitch
- 49.2 mil
- Aspect Ratio
- 16:9
- Backlight Technology
- Direct View LED
- Graphics Controller Manufacturer
- ARM
- Graphics Controller Model
- Mali-T860MP4
- Maximum LED Life
- 11.4 Year
- Video
- Scan Format
- 2160p
- Native Contrast Ratio
- 10,000:1
- Color Depth
- 13-bit
- Brightness
- 600 Nit
- Color Gamut
- 120% Rec. 709
- Network & Communication
- Ethernet
- Yes
- Wireless LAN
- Yes
- Interfaces/Ports
- USB
- Yes
- HDMI
- Yes
- Serial
- Yes
- Number of USB 2.0 Ports
- 2
- Number of USB 3.0 Ports
- 1
- Number of HDMI Inputs
- 4
- Number of HDMI Outputs
- 1
- USB Type-C
- Yes
- Number of Network (RJ-45) Ports
- 3
- Number of Audio Line Out
- 2
- Number of HDMI 2.0 Ports
- 5
- Software
- Operating System
- Android 9.0 Pie
- Power Description
- Input Voltage
- 120 V AC
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 104°F (40°C)
- Physical Characteristics
- Mount Type
- Wall Mountable
- Mount Surface
- Wall
- Height
- 112.1"
- Width
- 15.8 ft
- Depth
- 1.6"
- Weight (Approximate)
- 864.21 lb
- Miscellaneous
- Package Contents
- Preconfigured 4K All-In-One dvLED Displays
- Power Cord
- LAN Cable
- IR Extender Cable
- Remote Control
- Installation Guide
- Wall Mount
- Application/Usage
- Commercial
- Lobby
- Boardroom
- Auditorium
- Energy Star
- No
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Country of Origin
- China
- TAA Compliant
- No
