- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Packaged Quantity
- 1
- Product Type
- Open-frame LED Touchscreen Monitor
- Technical Information
- Screen Size Class
- 12"
- Viewable Screen Size
- 12.1"
- Screen Mode
- SVGA
- Response Time
- 35 ms
- Horizontal Viewing Angle
- 160°
- Vertical Viewing Angle
- 140°
- Mount Type
- Bracket-mountable
- Backlight Technology
- LED
- Features
- Dual Link-up
- On-screen Display (OSD)
- Video
- Maximum Resolution
- 800 x 600
- Color Supported
- 16.2 Million Colors
- Native Contrast Ratio
- 700:1
- Brightness
- 450 Nit
- Touchscreen Information
- Touchscreen Type
- 5-wire Resistive
- Interfaces/Ports
- DVI
- Yes
- USB
- Yes
- VGA
- Yes
- Number of VGA Ports
- 1
- Environmental Conditions
- Operating Temperature Range
- 32°F (0°C) to 113°F (45°C)
- Operating Humidity Range
- 5% to 95% (Non-condensing)
- Physical Characteristics
- VESA Mount Compatible
- Yes
- Height
- 9.9"
- Width
- 12.6"
- Depth
- 1.2"
- Weight (Approximate)
- 3.53 lb
